Machine Specifications
| Items | BNJ-51SY7 | ||||
|---|---|---|---|---|---|
| Machining Capacity | Distance between spindle end faces | 825 mm | |||
| Standard workpiece collection length | 120 mm | ||||
| Standard machining diameter | SP1 | 51 mm | |||
| SP2 | 51 mm | ||||
| Spindle | Max. spindle speed | SP1 | 5,000 min-1 | ||
| SP2 | 5,000 min-1 | ||||
| Collet chuck type | SP1 | H-S22、DIN177E、Hainbuch 51 | |||
| SP2 | H-S22、H-S20、DIN173E | ||||
| Power chuck type | SP1/SP2 | 6"/5"hollow chuck | |||
| Tool slide | Type of tool slide | TR1 | 12st. | ||
| TR2 | 8st. | ||||
| Revolving Tool | Revolving tool capacity | TR1 | Max.12 | ||
| TR2 | Max.8 | ||||
| Rotational speed of revolving tools | TR1 | 6,000min-1 | |||
| TR2 | 6,000min-1 | ||||
| Max. drilling diameter | TR1 | MAX ø13mm | |||
| TR2 | MAX ø13mm | ||||
| Max. tapping diameter | TR1 | MAX M12×1.75(S45C) | |||
| TR2 | MAX M12×1.75(S45C) | ||||
| Slide stroke | Turret slide stroke | X1 axis | 168mm | ||
| Z1 axis | 250mm | ||||
| Y axis | ±40mm | ||||
| Spindle slide stroke | X2 axis | 88mm | |||
| Z2 axis | 650mm | ||||
| Motor | Motor for spindle | SP1 Cs | 15/11kw (15 min/cont.) | ||
| SP2 Cs | 7.5/5.5kw (15 min/cont.) | ||||
| Machine size | Machine height | 1,775mm | |||
| Machine body dimensions | 2,881×1,578mm | ||||
| Machine Weight | 5,550 kg | ||||
BNJ-51SY7
Machining Capacity
- Distance between spindle end faces
- 825mm
- Standard workpiece collection length
- 120 mm
- Standard machining diameter[SP1/SP2]
- 51 mm
Spindle
- Max. spindle speed [SP1/SP2]
- 5,000 min-1
- Collet chuck type[SP1]
- H-S22、DIN177E、Hainbuch 51
- Collet chuck type[SP2]
- H-S22、H-S20、DIN173E
- Power chuck type [SP1/SP2]
- 6"/5"hollow chuck
Tool slide
- Type of tool slide[TR1]
- 12st.
- Type of tool slide[TR2]
- 8st.
Revolving Tool
- Revolving tool capacity[TR1]
- Max.12
- Revolving tool capacity[TR2]
- Max.8
- Rotational speed of revolving tools [TR1/TR2]
- 6,000min-1
- Max. drilling diameter [TR1/TR2]
- MAX ø13mm
- Max. tapping diameter [TR1/TR2]
- MAX M12×1.75(S45C)
Slide stroke
- Turret slide stroke [X1 axis]
- 168mm
- Turret Slide Stroke [Z1 axis]
- 250mm
- Turret Slide Stroke [Y axis]
- ±40mm
- Spindle slide stroke [X2 axis]
- 88mm
- Spindle Slide Stroke [Z2 axis]
- 650mm
Motor
- Motor for spindle [SP1 Cs]
- 15/11kw (15 min/cont.)
- Motor for spindle [SP2 Cs]
- 7.5/5.5kw (15 min/cont.)
Machine size
- Machine height
- 1,775mm
- Machine body dimensions
- 2,881×1,578mm
- Machine Weight
- 5,550 kg
